Wireless charging in the furniture do it yourself

I will show you how you can integrate wireless charging for your phone into almost any furniture.
Made her in the sofa with armrest in the form of a table.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

I ordered this charge on Ali Express.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

For the convenience of processing the grooves on the back of the table, I drew a circuit for processing slightly more than the dimensions of the coil and the board of our charging.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

I also painted a sticker layout on the front side to indicate the place of charging and ease of positioning of the charging device.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

Cut out mockups with a cutting plotter. For cutting a contour of processing the scrap of any light film is used. And for the sticker on the front part, a decorative film similar to scratched silver will be used.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

After the work done, we get these stickers.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

Now you can proceed to the processing of the tabletop with a manual router using the prepared template.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

As you can see, with the help of an improvised template, it turned out to make such a recess.in order not to weaken the front surface, the recess under the board is made not so deep, and the residual tabletop thickness at the coil location is 2 millimeters.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

Secure the coil and the board on simple screws. Under the board, there is a sufficient chipboard thickness for fastening through the holes, and the coil can be fixed with self-tapping screws screwed into the wall of the recess.
I drew the second contour on the template for the recess under the lid, but did not begin to make it. Everything closes and becomes on the armrest. Yes, and as it turned out, it is not so easy to get a flat line when machining with a manual mill. Make a recess under the cover will be obtained only with the help of a physical template and a copy cutter, or on a CNC machine.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

Pasted on the front side of the sticker with the logo. Of course, not everyone at home or at work has a cutting plotter, but as you already understood, a recess for the coil and a board can be made by eye and a sticker on the front part can be ordered from advertisers.
Wireless charging in the furniture with their own hands can be, deepening, painted, sides, grooves, stickers, assistance, done, fee, processing, coil, facial, make, just to, face, thickness, mill, hand, sticker

Everything is working...
